SPECIFICATIONS

Measuring Resistance Range: 60 Mohm

AC Current: 60A

Measuring Capacitance Range: 60mF

DC Voltage: 1000V

AC Voltage: 750V

Brand Name: WinAPEX

DC Current: 60A

Display Type: Digital display

DIY Supplies: ELECTRICAL

Choice: yes

Features:

• Leakage Detection: easily detect AC and DC leakage currents by clamping the Null and Live wires with pliers . Let you quickly master the safety status of your home circuit .

• High Precision Clamp Meter: measure small current.Provides a more detailed measurement with a resolution of 1mA for DC current and 0.1mA for AC current, automotive starting current quick measurement. Ideal for both home and professional applications.

• Screen rotation: freely control the screen with one button, improves the field of view for both hands operation

• Clear and large LCD Display: It adopts a 17mm character height LCD display with clear readings, and the screen brightness can be adjusted in 5 levels to better adapt to the external environment.

• Built-in battery: Supports Type-C charging, providing a continuous 20-hour battery life.

• Lightweight and Small Size, convenient for storage, comes with a special bag for keeping, simply pick it up and take it with you.

Multimeter Features:

AC voltage:6V/60V/600V/750V
DC voltage:6V/60V/600V/1000V
AC current:600mA/6A/60A
DC current: 6A/60A
NCV Test : support non contact voltage test
Temperature:(-20-1000 )℃/(0-1832 )℉
Capacitance:6nF/60nF/600nF/6uF/60uF/600uF/6mF/60mF
Resistance: 600Ω/6K Ω/60K Ω/600K Ω/6M Ω/60MΩ
Frequency:6Hz/60Hz/600Hz/6kHz/60kHz/600kHz/6MHz/10MHz
Diodes : support
Continuity: support
Live wire: support

Note: When testing DC current, you need to stay away from the object being measured. Press the ZORE key to clear it, and then clamp into the object being measured. The measured voltage cannot exceed the range allowed by the instruction manual.

Package List:

1 x Clamp Meter
1 x One Pair of Test leads
1 x User Manual
1 x thermometer couple
1 x Type-c Cable
1 x Storage Bag
